Electricity for the Trades, 3e (Petruzella)

Chapter 5   Simple, Series, and Parallel Circuits



1) Use of symbols tends to make circuit diagrams more complicated.



Answer:  FALSE

Difficulty: 1 Easy

Learning Objective:  Explain why symbols are used to represent electrical components.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



2) Electrical symbols always look like the part they represent.



Answer:  FALSE

Difficulty: 1 Easy

Learning Objective:  Explain why symbols are used to represent electrical components.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



3) All batteries supply DC power.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of basic electrical devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



4)  The output voltage connections of an AC power supply are identified as being positive or negative.



Answer:  FALSE

Difficulty: 1 Easy

Learning Objective:  Explain the symbols used to represent electrical components.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



5) The function of a circuit breaker is similar to that of a fuse.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the symbols used to represent electrical components.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







6) For a normally closed pushbutton, the contacts are closed (ON position) whenever the button is not pressed.



Answer:  TRUE

Difficulty: 2 Medium

Learning Objective:  Explain the symbols used to represent electrical components.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



7) All electrical load devices convert the energy of the source to another form of energy.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of basic electrical devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



8) Resistors are used to limit and control the flow of current in a circuit.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of basic electrical devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



9) Power distribution systems are often shown using single-line diagrams.



Answer:  TRUE

Difficulty: 2 Medium

Learning Objective:  Describe pictorial, schematic, wiring, block, and single-line diagrams.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



10) Unlike schematic diagrams, wiring diagrams show the actual connection and placement of all components.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Describe pictorial, schematic, wiring, block, and single-line diagrams.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







11) The symbol shown is used to represent a(n)





  1. A) AC power source.
  2. B) DC power source.
  3. C) open power source.
  4. D) closed power source.



Answer:  B

Difficulty: 1 Easy

Learning Objective:  Identify the symbol used to represent an electrical device.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation



12) The symbol shown is used to represent a(n)





  1. A) AC power source.
  2. B) DC power source.
  3. C) open power source.
  4. D) closed power source.



Answer:  A

Difficulty: 1 Easy

Learning Objective:  Identify the symbol used to represent an electrical device.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation







13) The symbol shown is used to represent

  1. A) wires crossed.
  2. B) a lamp holder.
  3. C) a circuit breaker.
  4. D) a fuse.



Answer:  C

Difficulty: 1 Easy

Learning Objective:  Identify the symbol used to represent an electrical device.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation







14) Which symbol would be used to represent the device shown?





A)

B)

C)

D)



Answer:  A

Difficulty: 1 Easy

Learning Objective:  Identify the symbol used to represent an electrical device.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation







15) Which symbol would be used to represent the device shown?



A)

B)

C)

D)



Answer:  C

Difficulty: 1 Easy

Learning Objective:  Identify the symbol used to represent an electrical device.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation



16) A fuse is used to:

  1. A) protect circuit wiring and equipment.
  2. B) allow only currents within safe limits to flow.
  3. C) automatically open the circuit when a higher current flows.
  4. D) All of the answers are correct.



Answer:  D

Difficulty: 2 Medium

Learning Objective:  Explain the operation of basic electrical devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







17) Which of the following electrical diagrams is easiest to read?

  1. A) pictorial
  2. B) wiring
  3. C) perspective
  4. D) schematic



Answer:  D

Difficulty: 2 Medium

Learning Objective:  Describe pictorial, schematic, wiring, block, and single-line diagrams.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



18) Which of the following electrical diagrams is impractical for complex circuits?

  1. A) pictorial
  2. B) wiring
  3. C) perspective
  4. D) schematic



Answer:  A

Difficulty: 1 Easy

Learning Objective:  Describe pictorial, schematic, wiring, block, and single-line diagrams.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







19) The electrical diagram shown would be classified as a ________ type.





  1. A) schematic
  2. B) block
  3. C) single line
  4. D) pictorial



Answer:  D

Difficulty: 1 Easy

Learning Objective:  Describe pictorial, schematic, wiring, block, and single-line diagrams.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



20) When loads are connected end to end they are said to be connected in series.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



21) For series connected loads, the same amount of current flows through each of the loads.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







22) For series connected loads, there are as many current paths as there are loads.



Answer:  FALSE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



23) For series connected loads, the higher the resistance of the load the less voltage it receives.



Answer:  FALSE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



24) In a series circuit, the current flow stops if the circuit is broken at any point.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



25) The truth table is for two switches connected in series used to control a lamp.





Answer:  FALSE

Difficulty: 2 Medium

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







26) The circuit shows two switches connected in parallel.





Answer:  FALSE

Difficulty: 2 Medium

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



27) When load devices are operated in parallel, each load operates independently of the others.



Answer:  TRUE

Difficulty: 2 Medium

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



28) When load devices are operated in parallel, the voltage across each load is the same as that of the voltage source.



Answer:  TRUE

Difficulty: 2 Medium

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



29) Connecting control devices in parallel results in an OR type of control circuit.



Answer:  TRUE

Difficulty: 1 Easy

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



30) The circuit shown would be classified as a ________ circuit.





  1. A) simple
  2. B) series
  3. C) parallel
  4. D) series/parallel



Answer:  A

Difficulty: 1 Easy

Learning Objective:  Identify a simple electrical circuit.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation







31) For the circuit shown, the voltage across each light would be:





  1. A) 12 V.
  2. B) 6 V.
  3. C) 4 V.
  4. D) 2 V.



Answer:  B

Difficulty: 2 Medium

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



32)  A string of lamps is connected in series to a voltage source. This connection would result in:

  1. A) two voltage paths.
  2. B) one voltage path.
  3. C) one current path.
  4. D) two current paths.



Answer:  C

Difficulty: 2 Medium

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







33) An AND-type control circuit consists of switches connected in:

  1. A) parallel.
  2. B) parallel and series combination.
  3. C) series.
  4. D) series and parallel combination.



Answer:  C

Difficulty: 1 Easy

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



34) Three lamps are connected in parallel to a 6-V source. The voltage across each lamp would be:

  1. A) 12 V.
  2. B) 6 V.
  3. C) 4 V.
  4. D) 2 V.



Answer:  B

Difficulty: 2 Medium

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



35) A string of lamps is connected in parallel to a voltage source. If one lamp burns out, all the other lamps:

  1. A) will go out.
  2. B) will get brighter.
  3. C) will not be affected.
  4. D) will get dimmer.



Answer:  C

Difficulty: 2 Medium

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation







36) If a circuit is constructed to allow the electrons to follow in only one possible path, the circuit is called:

  1. A) a series-parallel circuit.
  2. B) an open circuit.
  3. C) a series circuit.
  4. D) a parallel circuit.



Answer:  C

Difficulty: 2 Medium

Learning Objective:  Explain the operation of series-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



37) For the circuit shown, the voltage applied to each device would be





  1. A) 120 V.
  2. B) 90 V.
  3. C) 60 V.
  4. D) 30 V.



Answer:  A

Difficulty: 2 Medium

Learning Objective:  Explain the operation of parallel-connected loads and control devices.

Bloom’s:  Understand

Accessibility:  Keyboard Navigation



38) Breadboarding refers to:

  1. A) building a temporary version of a circuit.
  2. B) building a permanent version of a circuit.
  3. C) troubleshooting a circuit.
  4. D) repairing a circuit.



Answer:  A

Difficulty: 1 Easy

Learning Objective:  Know the terminology involved in constructing circuits from schematics.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation



39) When current stops flowing because of a break in a circuit, the condition is usually called

  1. A) an open circuit.
  2. B) a short circuit.
  3. C) a grounded circuit.
  4. D) an intermittent circuit.



Answer:  A

Difficulty: 1 Easy

Learning Objective:  Identify short and open circuit faults.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation



40) Which is the best description of a short circuit?

  1. A) The control device in the circuit is bypassed and a much higher than normal voltage is applied.
  2. B) The load in the circuit is bypassed, and a much larger than normal current flows.
  3. C) The protective device in the circuit is open and a much smaller than normal current flows.
  4. D) The power source in the circuit is interrupted and no current flows.



Answer:  B

Difficulty: 1 Easy

Learning Objective:  Identify short and open circuit faults.

Bloom’s:  Remember

Accessibility:  Keyboard Navigation

Additional information

Add Review

Your email address will not be published. Required fields are marked *
